AC power: external and DIN Rail PSU DC power: 9 VDC - 59 VDC Power consumption: 5 W Antennas: 2 x SMA female SIM: 2 x SIM card socket Interfaces: 4 x RJ45 port (10/100Base-T), 2 x serial port (2 x RS232, or 1 x RS232 + 1 x RS485) Digital inputs: 2 x digital inputs for detecting remote contact open/close Digital outputs: relay contact output, 30 VDC 1 A rating NO, NC and Common Protocol conversion: IEC 60870-5-104 in IEC 60870-5-101, IEC 60870-5-104 in DNP3, IEC 60870-5-104 in MODBUS (serial and TCP) Approvals and certificates: EN60950 safety approval, EN55022 and EN55024 EMC, IEC 61850-3 Routing features: firewall, port forwarding, BGPv4, OSPF, RIP (v1 and v2), IPSec/L2TP/GRE, SNMP v1/v2/v3, TLS 1.2, 802.1x authentication, IEC104, IPv4 and IPv6, DHCP server/client, DynDNS, NAT, NAT Traversal, NTP client, VLAN support, packet filtering Management: HTTP, HTTPS, CLI via Telnet or SSH, SNMP agent, TFTP client download/upload, SMS management support IP rating: IP31 Operating temperatures: -30 °C to 70 °C Authentication: RADIUS/TACACS Weight: 500 g Dimensions: 40 x 160 x 115 mm Product Specification
