- Unit type: end unit
- Frequency bands: 5.4 - 5.8 GHz
- Bandwidth: 10/20/40/80 MHz
- Modulation: MIMO-OFDM (BPSK/QPSK/16QAM/64QAM/256QAM)
- Adaptive modulation and coding: supported
- Tx power: up to 24 dBm
- Range: up to 40 km
- Ethernet: 1 x 10/100/1000 Mb/s, RJ45
- Power supply: Radwin PoE adapter
- Dimensions: 18.2 x 18.2 x 6 cm
- Weight: 0.5 kg
- Operating temperature: -35 °C to 60 °C
- IP protection: IP66
- Antenna type: integrated and connectorized, 2 x SMA-type connector for external antenna
- Antenna gain: 16 dBi
- Polarization: dual
- VSWR: 1.7:1
- Azimuth beamwidth: 17 °
